Phase 1
Phase 1 – Basic Electronics and Mobile Hardware
1
Day 1 – Basic electronics (theory)
Topics
Introduction to ohms law series and parallel circuits and basic components (Resistor, capacitor, diodes, transistor).
2
Day 2 – Multimeter mastery
Topics
Practical training on identifying components and measuring, voltage continuity and resistance.
3
Day 3 – Power supply (DC machine)
Topics
using ADC Power supply to direct short circuits (Flue /half shorts) and understanding boot sequence through circuit reading.
4
Day 4 – Assembly and disassembly techniques
Topics
for opening modern smart phones safely removing screws and organizing internal hardware.
5
Day 5 – Soldering basis
Topics
proper handling of a soldering iron, applying flux and soldering charging jacks and micro phone.
6
Day 6 – SMD rework station
Topics
Introduction to the hot air station, removing and replacing small SMD components (loose costs) without damaging PCB.
7
Day 7 – Oscilloscope (P&C)
Topics
Basic signal checking in the PCB measuring data lines and clock signals to diagnose complex boot failures.
